Disc Capsule Filter

Description Ordering information

GVS disk filters are a family of capsule filters specificallydesigned for small volume, critical applications of gas and

liquidfiltration in pharmaceutical and biotechnology.

Typical Applications

• Sterile venting of small containers, vessels

• Sterile ventilation of small bioreactors

• Small volume liquid application

Advantages

• Cost Saving

• Easy connection

• 100% Integrity Test

• Available in multiple choice of media and ratings

Construction of Materials

Filter Membrane: PTFE, PES, Nylon, PVDF, PP

Media Support: PP

End Caps: PP

Active Filtration Area

21cm²

Part No.	Membrane Type	Membrane Pore Size	Application	Fittings in	Fittings out	Revision
CDK50 = Disk Filter	PT = PTFE phobic	0004 = 0.04μm	G = Gen Purpose	4M2 = 1/4”-1/2” M.Step HB	4M2 = 1/4”-1/2” M.Step HB	0 = Rev.0	Order
-	PS = PES philic	0010 = 0.1μm	I = Ster. Gr. IR	1NM = 1/8’’ NPT	1NM = 1/8’’ NPT	1 = Ster Pack-R	Order
-	SH = PES phobic	0020 = 0.2μm	-	1LL = Luer	1LL = Luer	-	Order
-	NY = Nylon	0045 = 0.45μm	-	-	-	-	Order
-	PV = PVDF philic	0065 = 0.65μm	-	-	-	-	Order
-	PP = PP	0100 = 1μm	-	-	-	-	Order
